🐔 EC Broiler OS CAD Blueprint Edition
Telangana Poultry Standards, Climate & TSSPDCL Billing Configurator
Active Placement
30,000 Birds
Complete Setup Parameters
Configure structural, environmental, and financial variables below
1. Shed Physical Bounds & Lines
2. Ventilation & Airflow Profile
8 Drives
3. Electrical Load & Power Phase
4. Biology & Resource Logistics
Viewport: SHED VIEW
Drag mouse to orbit camera
Telangana Seasons
Toggle standard region templates to check auto-vent warnings:
Peak Summer (May) PRESET
42.0°C
Humidity Level
25%
External Airspeed
14 km/h
Thermal Alert! Increase VFD speed levels to extract peak heat mass.
TSSPDCL LT-IV Poultry Billing Engine
LT-IV Category
Tariff (per Unit)
₹ 6.00
TSSPDCL flat rate
Monthly Consumption
18,900
Calculated Units (kWh)
Est. Monthly Bill
₹ 1,16,520
Incl. Duty & Fixed Charges
* TSSPDCL poultry LT-IV calculates fixed charges at ₹50/kW of Contracted Load, Energy Charges at ₹6.00/kWh, and state Electricity Duty at ₹0.06/kWh.
Cycle biological readouts
FCR
1.615
Target baseline: < 1.60
EPEF index
391
Target baseline > 400
Livability
96.0%
Loss: 4.0%
ADG gain
64.6 g
daily weight delta
Live biomass limits comparison
38.3
KG / M² (LMT 36)
Flock mortality distribution
96.0%
SURVIVAL
Consolidated Technical Outputs & Specs
Structural & Lines Layout
Concrete Slab Footprint
1,672.3 m²
Feeder Layout Lines
4 Lines
Drinker Layout Lines
5 Lines
Placed Chicks
30,000
Floor Space per Bird
0.056 m²/bird
Climate Ventilation
Min. Flow Target (O₂ Baseline)
110,400 m³/h
Tunnel flow target
138,500 m³/h
Required Pad Area (150mm)
25.6 m²
Air Turn Exchange Time
12.5 seconds
Power Configuration & Backup
Electrical Load Rating
63 KVA
Transformer Sizing
63 KVA
Generator backup
63 KVA
Storage & operational Logistics
Peak Silo Tonnage Buffer
19.2 MT
Water-to-Feed Ratio
2.20 : 1
Tunnel Exhaust Fans Needed
12 Units
